Measure the wall you actually have
FieldCAD starts with site reality instead of a blank CAD file. A guided photo becomes a scaled working elevation after you verify one real distance.
PHOTO → MEASURED ELEVATION → CAD
Turn a wall photo into a measured elevation—and a field-ready DXF.
Capture the surface, anchor it with a tape-verified distance, lay out the work, and deliver files the field and shop can use.
A focused field workflow
Capture, calibrate, place, and deliver without rebuilding the entire room.
- Photo-guided wall capture
- Tape-verified scale
- Restricted 2.5D layout
- Measured PDF and layered DXF
Built for finish trades
Document the surfaces, obstacles, openings, and proposed work that control cabinet, millwork, tile, shelving, and hood installations.
FINISH TRADES
Start with the work in front of you.
CABINET & MILLWORKCabinet and millwork field measurementsCapture a cabinet install wall, verify scale, place casework, and export a measured PDF or layered DXF.↗TILE & BACKSPLASHBacksplash measurement and tile layoutCreate a scaled elevation for outlets, edges, corners, and the layout lines that control installation.↗SHELVING & HOODSShelving and range hood site surveysCoordinate mounted components, clearances, utilities, and neighboring finishes on one measured wall.↗
